LPG Cylinder Filling Scale
Our LPG flowmeters has positive displacement 4 pistons and sensitively adjustable magnetic coupling.
It has evaluation certificate from Miscarea Romana Pentru Calitate (Romania) according to MID OIML R117-1/2007 requirements.
| Specification | MECHANICAL LPG CYLINDER FILLING SCALE NE-M-10 | ELECTRONIC LPG CYLINDER FILLING SCALE NE-E-10 | MECHANICAL LPG CYLINDER FILLING SCALE NE-M-32 | ELECTRONIC LPG CYLINDER FILLING SCALE NE-E-50 | MECHANICAL LPG CYLINDER FILLING SCALE NE-M-110 | ELECTRONIC LPG CYLINDER FILLING SCALE NE-E-110 |
|---|---|---|---|---|---|---|
| Weighing Range | From 0,00 Kg to 10,00 Kg | From 0,00 Kg to 10,00 Kg | From 0,00 Kg to 32,00 Kg | From 0,00 Kg to 50,00 Kg | From 0,00 Kg to 110,00 Kg | From 0,00 Kg to 110,00 Kg |
| Weighing Sensitivity | 10 gr | 10 gr | 10 gr | 10 gr | 10 gr | 10 gr |
| Filling Accuracy | 100 gr | 100 gr | 100 gr | 100 gr | 100 gr | 100 gr |
| Number of Formulas | — | 9 different formulas | — | 9 different formulas | — | 9 different formulas |
| Scale’s Weight | 10 Kg | — | 95 Kg | — | 110 Kg | 110 Kg |
| Input Power Ratings | — | 12 V-DC 280 mA | — | 12 V-DC 280 mA | — | 12 V-DC 280 mA |
| Load Cell Capacity | — | 300 Kg single-point ATEX-certified load cell | — | 300 Kg ATEX-certified single-point load cell | — | 300 Kg ATEX-certified single-point load cell |
| Outer Dimensions | 1120 × 520 × 350 mm | 1100 × 520 × 305 mm | 1400 × 598 × 365 mm | 1600 × 598 × 365 mm | 1960 × 598 × 365 mm | 1960 × 598 × 365 mm |
| Max. Operating Temperature | +50 °C | +50 °C | +50 °C | +50 °C | +50 °C | +50 °C |
| Working Air Pressure | 6 – 8 Bar | 6 – 8 Bar | 6 – 8 Bar | 6 – 8 Bar | 6 – 8 Bar | 6 – 8 Bar |
| LPG Pressure | 6 – 16 Bar | 6 – 16 Bar | 6 – 16 Bar | 6 – 16 Bar | 6 – 16 Bar | 6 – 16 Bar |
| ATEX Marking / Certificate No. | II 2G Ex IIA T4 Gb; II 2G Ex h II A T4 Gb; IEP 13 ATEX 0179X | II 2G Ex IIA T4 Gb; II 2G Ex h II A T4 Gb; IEB 16 ATEX 0391X | II 2G Ex IIA T4 Gb; II 2G Ex h II A T4 Gb; IEP 13 ATEX 0179X | II 2G Ex IIA T4 Gb; II 2G Ex h II A T4 Gb; IEB 16 ATEX 0391X | II 2G Ex IIA T4 Gb; II 2G Ex h II A T4 Gb; IEP 13 ATEX 0179X | II 2G Ex IIA T4 Gb; II 2G Ex h II A T4 Gb; IEB 16 ATEX 0391X |
| Installation Type | Stationary | Stationary | Stationary | Stationary | Stationary | Stationary |
| Tare Weight Input | Manual by the operator | Manual by the operator | — | Manual by the operator | Manual via scale keypad by the operator | Manual via scale keypad by the operator |
| Filling Head | Equipped with camp-valve filling head | Equipped with camp-valve filling head | — | Equipped with F-valve type filling head | Equipped with F-valve type filling head | Equipped with F-valve type filling head |
| Gas Stop Valve | — | — | Equipped with single-stage gas stop valve | — | — | — |
